[Lifetime Warranty] 1N34A 1N34 Schottky Barrier Rectifier Blocking Diodes 50mA 65V

1N34A 1N34 Schottky Barrier Rectifier Blocking Diodes 50mA 65V

Key Features

• Type: Schottky Barrier Rectifier Diode
• Maximum Average Forward Current: 50mA
• Maximum Repetitive Reverse Voltage: 65V
• Low Forward Voltage Drop
• Package Type: DO-35 (DO-204AH)
• Lead Style: Axial

Replaces / Cross-Reference Part Numbers

• 1N34A
• 1N34
• IN34A
• IN34

Compatibility & Fitment

• Designed for high-frequency applications
• Suitable for use in AM, FM, and TV radio signal detection
• Applicable in switch-mode power supplies and DC-to-DC converters
• Commonly used in audio circuits, including musical effects pedals and clippers
• General-purpose signal rectification and blocking

When to Replace

• Component fails open or short circuit tests with a multimeter
• Incorrect forward voltage drop reading
• Visible damage, such as cracks or burn marks on the casing
• Associated circuit is malfunctioning or providing no output

Installation Tips

• Verify correct polarity before soldering. The band on the diode body indicates the cathode (-).
• Use a heat sink on the lead between the component and the solder joint to prevent heat damage.
• Avoid applying excessive mechanical stress or bending the leads too close to the component body.
• Ensure the component is installed in a circuit that operates within its specified voltage and current ratings.
