AZ00389826
6931EL3003D & 6931EL3004B Dryer Thermal Fuse Kit
Sold 4,404
Normal
15 - 20 minutes
$8.82
$9.79
Save $0.97
In Stock
Fast delivery
Confirm the fit for your model
Find your model number and check it here to see if the part fits.
Description
Description
6931EL3003D & 6931EL3004B Dryer Thermal Fuse Kit
Key Features
- Kit includes two components: 1 x 6931EL3003D high-limit thermal fuse and 1 x 6931EL3004B thermostat assembly.
- The thermal fuse shuts off the heating element or burner when the dryer overheats, acting as a safety device.
- Fuse 6931EL3003D is rated at 140 degrees Celsius.
- Features a flush-mounted design with two 1/4-inch male terminals.
Replaces / Cross-Reference Part Numbers
- 6931EL3001E
- 6931EL3001F
- 6931EL3003C
- 6323EL2001B
- PS3530485
- 1268366
Compatibility & Fitment
- Designed for direct replacement on select dryer models.
- Compatible with specific LG and Kenmore brand dryers.
- Verify compatibility by checking your appliance's original part numbers.
When to Replace
- Dryer drum tumbles but produces no heat.
- Dryer takes too long to dry clothes.
- Dryer overheats and shuts down prematurely.
- Existing thermal fuse shows no continuity when tested with a multimeter.
Installation Tips
- Disconnect the dryer from the power supply before beginning any repair.
- The thermal fuse is a single-use safety component and cannot be reset.
- Before replacing a blown fuse, inspect and clean the dryer's venting system to resolve the root cause of overheating.
